Workflow - PraisonAI

The workflow command manages reusable multi-step workflows stored in .praisonai/workflows/.

Install requirement: praisonai workflow requires pip install praisonai (the full wrapper). On a standalone pip install praisonai-code install these subcommands (list, show, run) exit 1 with workflow requires the full wrapper. Install the full wrapper: pip install praisonai — a single-line hint, no Rich traceback (PR #2854).

Quick Start

praisonai workflow list

# List available workflows
praisonai workflow list

# Execute a workflow
praisonai workflow run "Research Blog" --tools tavily --save

# Quick workflow without creating a file
praisonai "What is AI?" --workflow "Research,Summarize" --save

# With step actions
praisonai "GPT-5" --workflow "Research:Search for info,Analyze:Analyze findings,Write:Write blog"

Two Ways to Run Workflows

Method	Command	Use Case
Template-based	`praisonai workflow run "name"`	Reusable, complex workflows with per-step agents
Inline	`praisonai "prompt" --workflow "step1,step2"`	Quick, ad-hoc workflows

Template-Based Workflows

List Workflows

praisonai workflow list

Expected Output:

╭─ Available Workflows ────────────────────────────────────────────────────────╮
│  📋 deploy - Deploy application to production                               │
│  📋 Research Blog - Research and write blog posts                           │
╰──────────────────────────────────────────────────────────────────────────────╯

Execute Workflow

praisonai workflow run "Research Blog"

Execute with Options

# With variables
praisonai workflow run deploy --workflow-var environment=staging --workflow-var branch=main

# With tools and save output
praisonai workflow run "Research Blog" --tools tavily --save

# With planning mode (AI creates sub-steps for each workflow step)
praisonai workflow run "Research Blog" --planning --verbose

# With memory
praisonai workflow run "Research Blog" --memory

Resume an Interrupted Workflow

If a workflow stops partway — a crash, a timeout, or a Ctrl-C — resume it from the last saved step instead of starting over. A checkpoint is saved after each completed step; --resume reads it and continues from the next step.

# Save a checkpoint after each step (name defaults to the workflow name)
praisonai workflow run release-notes --checkpoint run-1

# ...interrupted at step 3 of 6...

# Continue from step 3 — prints "Resumed from step 3"
praisonai workflow run release-notes --resume

--resume, --checkpoint, and --rebase-checkpoint apply to markdown workflows run through WorkflowManager. YAML workflows use a different engine and do not support these flags yet.

If you edit the workflow file between saving and resuming, a definition fingerprint guards against landing on the wrong step. Whitespace and comment-only edits keep the same fingerprint, so resume still works. Changing steps or agent configuration changes the fingerprint and resume refuses:

# After editing the workflow (add/reorder/remove a step, or change agent config):
praisonai workflow run release-notes --resume
# → Error: workflow definition changed since the checkpoint (fingerprint mismatch:
#          checkpoint=a1b2c3d4e5f6, current=9f8e7d6c5b4a).
#          Re-run without --resume to start fresh, or pass --rebase-checkpoint to
#          deliberately continue at the same step index against the edited definition.

# Force resume at the same step index against the edited workflow (logs a warning):
praisonai workflow run release-notes --resume --rebase-checkpoint

Pick between the three options with this decision guide: Here is the full save → interrupt → list → resume flow end to end:

Manage Checkpoints

List saved workflow checkpoints, or delete one you no longer need.

# List all saved checkpoints
praisonai workflow checkpoints

# Delete a checkpoint by name
praisonai workflow checkpoints --delete release-notes

Expected Output:

                          Workflow Checkpoints
┏━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━┓
┃ Name         ┃ Workflow       ┃ Completed Steps ┃ Fingerprint  ┃ Saved At            ┃
┡━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━┩
│ release-notes│ release-notes  │ 2               │ a1b2c3d4e5f6 │ 2026-08-19T11:04:12 │
└──────────────┴────────────────┴─────────────────┴──────────────┴─────────────────────┘

Checkpoint files live in {workspace}/.praisonai/checkpoints/{name}.json. The Fingerprint column shows - for checkpoints saved before fingerprinting existed.

Show Workflow Details

praisonai workflow show deploy

Create Workflow Template

praisonai workflow create my_workflow

Inline Workflows

Run workflows directly from the command line without creating a template file:

# Simple format: step names only
praisonai "What is Python?" --workflow "Research,Analyze,Summarize"

# Detailed format: step_name:action
praisonai "AI trends" --workflow "Research:Search for AI trends,Write:Write a blog post"

# With all options
praisonai "GPT-5 features" --workflow "Research,Write" --tools tavily --save --verbose

Inline Workflow Format

Format	Example	Description
Simple	`"Research,Summarize"`	Step name = action
Detailed	`"Research:Search for info,Write:Write blog"`	Custom action per step

CLI Options

Workflows use global flags (same as other commands):

Flag	Description
`--workflow-var key=value`	Set workflow variable (can be repeated)
`--llm <model>`	LLM model (e.g., `openai/gpt-4o-mini`)
`--tools <tools>`	Tools (comma-separated, e.g., `tavily`)
`--planning`	Enable planning mode (AI creates sub-steps)
`--memory`	Enable memory
`--verbose`	Enable verbose output
`--save`	Save output to file
`--checkpoint <name>`	Save/resume under this checkpoint name (markdown workflows; defaults to the workflow name)
`--resume`	Continue from the last saved checkpoint (markdown workflows only)
`--rebase-checkpoint`	Force resume at the same step index despite a workflow definition change (logs a warning)

Workflow YAML Schema

`framework:` key

YAML workflow files accept a top-level framework: key. Only praisonai (case-insensitive) is supported by the native execution engine.

Value	Behaviour
Omitted or empty	Defaults to `praisonai` — no change
`praisonai` (any case)	Runs normally
Any other value (`crewai`, `autogen`, …)	Raises `ValueError` at `Workflow.run()` time

# my_workflow.yaml
framework: praisonai   # ✅ OK — or simply omit this key
roles:
  researcher:
    backstory: "You are a researcher"
    goal: "Research the topic"

If you set a different framework name, PraisonAI raises immediately rather than silently running the native engine:

ValueError: Workflow YAML framework='crewai' is not supported by the native
PraisonAI execution engine. Only 'praisonai' is supported. Either remove the
'framework:' key or set it to 'praisonai'.

The framework: validation only applies to the native YAML workflow executor (Workflow.run()). To run CrewAI or AutoGen, use the framework adapters path via praisonai --framework crewai agents.yaml — see Framework Availability for adapter details.

Workflow File Format

Workflows are stored in .praisonai/workflows/ as Markdown files with YAML frontmatter:

---
name: Research Blog
description: Research and write blog posts
default_llm: gpt-4o-mini
variables:
  topic: AI trends
---

## Step 1: Research
Research the topic thoroughly.

\`\`\`agent
role: Researcher
goal: Find comprehensive information
\`\`\`

\`\`\`tools
tavily_search
\`\`\`

\`\`\`action
Search for information about {{topic}}
\`\`\`

## Step 2: Write Blog
Write a blog post based on research.

\`\`\`agent
role: Writer
goal: Write engaging content
\`\`\`

context_from: [Research]

\`\`\`action
Write a blog post about {{topic}} using the research data.
\`\`\`

How It Works

Load: Workflow file is loaded from .praisonai/workflows/
Variables: Variables are substituted into step prompts
Execution: Each step is executed sequentially with its configured agent
Context: Results from each step are passed to the next

Exit Codes

praisonai workflow now returns process exit codes that reflect what actually happened, so CI, benchmarks, and shell pipelines can branch on success without parsing stdout.

Command	Success	Failure
`workflow run <name>`	`0` when every step succeeds	non-zero when any step fails, the file is missing, or (hierarchical) the manager rejects or raises
`workflow validate <file>`	`0` on a valid file	non-zero on validation errors
`workflow list` / `workflow show`	`0`	—
`workflow help`	`2`	— (Typer rejects the bare `help` topic before the legacy path)

Behaviour change (PraisonAI PR #4946). An agent/action step that produces no output is now a step failure, not a warning. Previously every path in the workflow handler exited 0 even when steps failed — the fix behind .github/workflows/praisonai-pr-review.yml no longer passing unconditionally. Any recipe, tutorial, or CI job that shells out to praisonai workflow run and swallows the exit code should be updated: a non-zero exit is now a signal, not noise.

Before the fix, a failed model call was silently swallowed and the run still reported success:

[Writer] Authentication failed for openai.
⚠️  Step 'haiku': Output is None.
✅ Workflow completed successfully!
EXIT=0

After the fix, the same run fails loudly:

❌ Workflow failed: haiku: agent produced no output (None) — the model call most likely failed
EXIT=1

handler steps are unchanged — a custom Python handler may legitimately return None. Only agent and action steps are treated as failures when they produce nothing.

The `error` field on a failed result

A failed Workflow.start() (or .run()) result carries an error string describing the first failure. It is populated whenever the final workflow status is failed; a successful run does not set it.

from praisonaiagents import Workflow

result = Workflow(...).start()
if result.get("error"):
    print("workflow failed:", result["error"])

Failure	Example `error` value
LLM produced `None`	`haiku: agent produced no output (None) — the model call most likely failed`
Manager rejected the step (hierarchical)	`Manager rejected step 'review': output is off-topic`
Manager call raised (hierarchical)	the underlying exception text from the manager LLM call

Hierarchical Mode Validation

When a workflow runs with process="hierarchical", a manager LLM judges each step’s output. Three fail-open defects are fixed as of PR #4946:

Manager rejections are honoured. The manager verdict is parsed with the engine’s own _parse_json_output helper (the same one used elsewhere in the engine), which strips the ```json fences models routinely emit. A bare json.loads used to raise JSONDecodeError on every fenced reply and substitute {"approved": true, "reason": "assuming success"}, silently discarding a rejection. Now "approved": false fails the run.
An unreadable verdict fails closed. If the manager response cannot be parsed into a dict, it is treated as not approved rather than assumed successful.
A manager outage fails the run. Exceptions raised during the manager call are now failures, not a logged-and-ignored pass.
A step that produced nothing is judged too — the same no-output rule from the sequential path applies here.

Examples

Research Workflow

# Execute with tools
praisonai workflow run "Research Blog" --tools tavily --save

# With planning mode (AI creates sub-steps for each step)
praisonai workflow run "Research Blog" --planning --verbose

Deployment Workflow

# With variables
praisonai workflow run deploy --workflow-var environment=staging --workflow-var branch=main

Release Workflow

praisonai workflow run release --workflow-var version=1.2.0

Programmatic Usage

from praisonaiagents import AgentFlowManager

manager = WorkflowManager()

# Execute a workflow
result = manager.execute(
    "deploy",
    executor=lambda prompt: agent.chat(prompt),
    variables={"environment": "production"}
)

Best Practices

Use variables for environment-specific values to make workflows reusable.

Workflows execute steps sequentially. Ensure each step can complete independently.

Do	Don’t
Use variables for environment values	Hardcode environment names
Keep steps focused and atomic	Create monolithic steps
Add descriptions to workflows	Skip documentation
Test workflows in staging first	Deploy directly to production

Auto-Generate Workflows

Fixed in PR #2147: praisonai workflow auto was non-functional in all previous releases — every call raised a NameError on _models_cache and surfaced as Generation failed: in the CLI. The command now works as documented below.

Generate workflow YAML files automatically from a topic description:

# Basic auto-generation
praisonai workflow auto "Research and write a blog post"

# With specific pattern
praisonai workflow auto "Analyze market trends" --pattern orchestrator-workers

# With output file
praisonai workflow auto "Customer support routing" --pattern routing --output support_workflow.yaml

Available Patterns

Pattern	Description	Use Case
`sequential`	Agents work one after another	Default, step-by-step tasks
`parallel`	Agents work concurrently	Independent subtasks
`routing`	Classifier routes to specialists	Different input types
`loop`	Repeat steps until condition met	Iterative processing
`orchestrator-workers`	Central orchestrator delegates dynamically	Complex decomposition
`evaluator-optimizer`	Generate-evaluate loop until quality met	Content refinement

Pattern Examples

Orchestrator-Workers

Central orchestrator analyzes the task and delegates to specialized workers:

praisonai workflow auto "Comprehensive market analysis and report" --pattern orchestrator-workers

Generated workflow includes:

Orchestrator: Analyzes task, determines required workers
Workers: Researcher, Analyst, Writer (run in parallel)
Synthesizer: Combines all worker outputs

Evaluator-Optimizer

Iterative refinement with feedback loops:

praisonai workflow auto "Write and polish a high-quality article" --pattern evaluator-optimizer

Generated workflow includes:

Generator: Creates initial content
Evaluator: Scores content (1-10), provides feedback
Loop: Continues until score >= 7 or max iterations

Parallel

Multiple agents work concurrently:

praisonai workflow auto "Research from news, social media, and academic sources" --pattern parallel

Routing

Classifier routes to specialized agents:

praisonai workflow auto "Handle technical, billing, and general customer requests" --pattern routing

​Quick Start

​Two Ways to Run Workflows

​Template-Based Workflows

​List Workflows

​Execute Workflow

​Execute with Options

​Resume an Interrupted Workflow

​Manage Checkpoints

​Show Workflow Details

​Create Workflow Template

​Inline Workflows

​Inline Workflow Format

​CLI Options

​Workflow YAML Schema

​framework: key

​Workflow File Format

​How It Works

​Exit Codes

​The error field on a failed result

​Hierarchical Mode Validation

​Examples

​Research Workflow

​Deployment Workflow

​Release Workflow

​Programmatic Usage

​Best Practices

​Auto-Generate Workflows

​Available Patterns

​Pattern Examples

​Related

Quick Start

Two Ways to Run Workflows

Template-Based Workflows

List Workflows

Execute Workflow

Execute with Options

Resume an Interrupted Workflow

Manage Checkpoints

Show Workflow Details

Create Workflow Template

Inline Workflows

Inline Workflow Format

CLI Options

Workflow YAML Schema

`framework:` key

Workflow File Format

How It Works

Exit Codes

The `error` field on a failed result

Hierarchical Mode Validation

Examples

Research Workflow

Deployment Workflow

Release Workflow

Programmatic Usage

Best Practices

Auto-Generate Workflows

Available Patterns

Pattern Examples

Related
